High Precision Cylinder Screen Welding Machine For Oil / Gas Filtration​

1, Dimension 9500*2000*3000mm.

2, Tube diameter 600-1200mm.

3, The maximum length of screen is 4000mm,in this range,you can produce tube as your requirements.

4, Screen slit gap can be adjusted according to the requirements(in the case of parking or not),solt size range:0.2mm-16mm.

5, tolerance clearance ±0.02mm.

6, maximum speed of spindle:10 rpm.

7, Mitsubishi servo motor,motor power:4.5kW two motor,3.5kW one motor .

8, Transmission medium adopts Using linear guide and ball screw

9, nominal voltage :380V/50Hz.

10, welding transformer :200kVA.

11, We offer two sets of tooling for free.,The customer can choose which are between 80mm to300mm

2. Applications

Cylinder Screen Welding Machine(wrap wire screen machine), also named johnson screen welding machine, is usually used in producing small diameter screen tube, with its higher precision, which is widely used in Chemicals, sugar, micro filter applications.

3. Parameter

4. Features and Advantages

A. low noise

B. less power consumption

C. safety

D. easy to operate

E. high welding precision

Advantages: Domestic famous bearings, Internal famous servo motor, less power consumption,easily operation

5. Services

Shijiazhuang Renchun Mesh Equipment Co.,Ltd.(primitive name -Hebei Zhengda Machinery company) is a professional manufacturer which is specialized in product developing, designing and machine manufacturing .

With higher researching and developing ability of parent company(Shijiazhuang bearing equipment co., LTD.),We have designed wedge wire screen welding machine.

We satisfy our client by the perfect design,new technology,practical function and easy operation.

Our machines have obtained the patent for our technology.

Our machine products:NC wrap wire screen welding machine,wedge wire screen welding machine ,oil filter welding / slotted screen welding machine and johnson screen welding machine.

With perfect machines,we can also product various type of screen media: johnson screen,wedge wire screen cylinder, water well screen tank, mine screen,screen panel ,screen basket ,sieve bend and so on.

Application usage:Petroleum chemical industry, mining, water treatment, as well as food.

Sale market:

Domestic market: Heilongjiang , Liaoning, Tianjin, Hebei, Henan, Shandong, Shanghai, Guizhou, Hubei, Shanxi, jiangsu, etc.

Foreign market: the United States, Brazil, Italy, Belgium, South Korea, Singapore, Tunisia, Turkey, Russia, India, etc.

Enterprise development concept and service

　　friendly cooperation

　　development and innovation,

　　mutual benefit

Welcome friends to our factory,we must make your trip worth well.
