    Wedge Wire Screen Welding Machine for For Filtration , Separation And Retention Media

    Ask Lasest Price
    Brand Name : RENCHUN
    Model Number : HWJ300
    Certification : CE ISO
    Payment Terms : T/T
    Supply Ability : 20 sets per year
    Delivery Time : 90 work days
    • Product Details
    • Company Profile

    Wedge Wire Screen Welding Machine for For Filtration , Separation And Retention Media

    On Sale Wedge Wire Screen Welding Machine for Beverage Industry


    General Description


    Wedge wire is a welded steel structure, mainly used for filtration, separation and retention media.

    It consists of surface profiles, usually V-shaped, that are resistance welded onto support profiles. The distance between the surface profiles is controlled very accurately, as it forms the slot through which the filtrate flows.

    In case of V-shaped surface profiles conical slots are created.


    Filtrations Direction


    The direction of the flow is determined by the position of the surface profiles in relation to the support profiles. Wedge wire screens are either flow-out-to-in (FOTI) or flow-in-to-out (FITO)


    Technical Parameter


    Specification

    Tube Diameter

    Tube Length

    Wire Range

    Welding Speed

    Slot Size

    Precision

    HWJ300

    50~300mm

    6000mm

    0.75~1.5mm

    6~30rpm

    0.05~5mm

    within 0.01mm


    Advantages


    1. Non-clogging: the continuous slot formed by the V-shaped surface wires ensures a two-point contact between the particles and the slot, which minimizes clogging.

    2. High-precision slot sizes: precise slot sizes are available to meet customer´s requirements.

    3. Surface filtration: the V-shaped surface wires allow easy cleaning by mechanical scraping or back flushing.

    4. Low pressure-drop

    5. Strong construction: for most applications, the wedge wire screen is self-supporting, because of the welding at each intersection.
