Water Well Welded Wire Mesh Machine Making Stainless Steel 316 Material

1. Shijiazhuang Renchun Mesh Equipment Co., Ltd. Introduction

Shijiazhuang Renchun Mesh Equipment Co., Ltd. is specialized in designing, developing, and manufacturing mesh welding machines. Its CNC mesh welding machine has gained good reputation around the world because of perfect design, advanced technology, practical performance, and simple operation.

And the company has gained national patents on the mesh welding machine.
Company offer three packages of service , timely after-sales service, and free technical training.
Our company is willing to offer perfect service and meet customers’ special requirement.


2. Main application of Wedge wire screen welding machine

The wedge wire screen welding machine is an ideal for making wedge wire screen, wire wrapped screen, johnson screen, and water well screen etc.

Customer question

1 What's the precision of wedge wire screen welding machine?

Generally ,the precision can be reach +/-0.01mm with perfect wire

2 Are you a factory or trade company?

Glad to know we are a factory with 20 years, experience.

3 Where is your factory located in? whenre can we buy wedge wire screens?

Our factory located in South Gate of No.11,Changsheng street,

2. Wedge wire screen welding machine description
HWJ200*2000

NCHWJ200*2000
1, Tube diameterФ50mm-Ф200mm,
2 , The maximum length of screen is 2000mm, in this range,you can produce tube as your requirements.
3, Screen slit gap can be adjusted according to the requirements(in the case of parking or not), range:0.05mm-5mm.
4, tolerance clearance ±0.01mm,
5, maximum speed of spindle:30rpm,
6, welding transformer power:200KVA
7, Mitsubishi servo motor,motor power:2.5kW two motor,
8, Transmission medium adopts Using linear guide and ball screw,
9, Materials: Stainless Steel or low carbon steel wire,
10, We offer two sets of tooling for free, The customer can choose which are

3. Normal maintence check list

Daily check the Auto oil pump the oil level tank .
Weekly check the Cooling water temperature aand make sure not over heat and the water clarity if not acceptable then must replace immediately.
Monthly every parts of the bolts and nuts from this machines need to be checked and verified the tightenness.
Every three months t, the machine main roller ball bearing need to be checked and greased properly and fully.
planet reducer with electrical motor need to be kept clean at all time in order to avoid the operation.
Check the power cables at the all time and weekly check to make sure any damages .
Monthly check the copper electric plate and the connect contact parts are well connected .
Check the temperature on all the power cable parts or connection parts.

4. Our customer

During past two years, We had exported the machine to many countries. Such as America, Russia, Italy, Korea, India, Brazil, and so on.

Shijiazhuang Renchun Mesh Equipment Co.,Ltd.(primitive name -Hebei Zhengda Machinery company) is a professional manufacturer which is specialized in product developing, designing and machine manufacturing .

With higher researching and developing ability of parent company(Shijiazhuang bearing equipment co., LTD.),We have designed wedge wire screen welding machine.

We satisfy our client by the perfect design,new technology,practical function and easy operation.

Our machines have obtained the patent for our technology.

Our machine products:NC wrap wire screen welding machine,wedge wire screen welding machine ,oil filter welding / slotted screen welding machine and johnson screen welding machine.

With perfect machines,we can also product various type of screen media: johnson screen,wedge wire screen cylinder, water well screen tank, mine screen,screen panel ,screen basket ,sieve bend and so on.

Application usage:Petroleum chemical industry, mining, water treatment, as well as food.

Sale market:

Domestic market: Heilongjiang , Liaoning, Tianjin, Hebei, Henan, Shandong, Shanghai, Guizhou, Hubei, Shanxi, jiangsu, etc.

Foreign market: the United States, Brazil, Italy, Belgium, South Korea, Singapore, Tunisia, Turkey, Russia, India, etc.

Enterprise development concept and service

　　friendly cooperation

　　development and innovation,

　　mutual benefit

Welcome friends to our factory,we must make your trip worth well.
