    HWJ1000 Oil Well Wedge Wire Screen Machine 2300MM Height 6-30 RPM

    Ask Lasest Price
    Brand Name : Renchun
    Model Number : HWJ1000
    Payment Terms : D/P, T/T, Western Union, MoneyGram, D/A, L/C
    Delivery Time : 30-90 days
    • Product Details
    • Company Profile

    HWJ1000 Oil Well Wedge Wire Screen Machine 2300MM Height 6-30 RPM

    HWJ1000 Oil Well Wedge Wire Screen Machine 2300MM Height 6-30 RPM

    Shijiazhuang Renchun Mesh Equipment Co.,Ltd.(primitive name -Hebei Zhengda Machinery company) is a professional manufacturer which is specialized in product developing, designing and machine manufacturing .
    With higher researching and developing ability of parent company(Shijiazhuang bearing equipment co., LTD.),We have designed wedge wire screen welding machine.
    We satisfy our client by the perfect design,new technology,practical function and easy operation.
    Our machines have obtained the patent for our technology.
    Our machine products:NC wrap wire screen welding machine,wedge wire screen welding machine ,oil filter welding / slotted screen welding machine and johnson screen welding machine.
    With perfect machines,we can also product various type of screen media: johnson screen,wedge wire screen cylinder, water well screen tank, mine screen,screen panel ,screen basket ,sieve bend and so on.
    Application usage:Petroleum chemical industry, mining, water treatment, as well as food.


    Wedge wire screen welding machines adopts resistance welding fundamental.

    Controlled by the Numeral control system, the servo motor drives the ball screw as well as the drawing disk which is mounted on the straight rail, so the slot clearance can be adjusted by touching the control screen without stopping the machine.


    No.ITEMData
    1Diameter of screenMin.300mm,Max.1000
    2Max.Length of filter tube4000mm
    3Rod and wire diamter1.2 to 3mm(profile wire)
    4MaterialCarbon steel,stainless steel
    5Servo motorTwo sets:7KW,One set:5KW
    6Power of welding Transformer200kva
    7Welding speed6-30rpm
    8Slot0.2-16mm
    9Precision of slot+/-0.03mm
    10Gross weight12 Ton
    11Outside DimensionL13000mm*W1500mm*H2100mm




    It is easy to change the data on the touching screen. Lock-expanding ring is equipped on the machine. After the operator feeds the longitudinal wire, expand and lock the wire with the ring.

    It saves time and material during unload the filter tube.It is easy to learn how to control the machine.


    The wire mesh filter welding machines,developped and produced by us,feature low noise,low energy consumption,steady function,and safety. the electric system adopts Mitsubishi E60.the feeding spindle and the main spindle adopt Mitsubishi AC servo motors and drivers. controlled by the control system,the servo motor drivers the ball screw which drivers the wire-drawing disk.sliding on the straight rail,the wire -drawing disk moves according to the order of the control system.the slot clearance can be adjusted as requirement.the data displayed on the screen can be reset easily.lock-expanding ring is equipped on the machine. after the operator feeds the longitudinal wire,expand and lock the wire with the ring.it saves time and material during unload the filter tube. the machines are ideal for making filter tubes of oil filtering,wtaer cleaning and water well filtering,as well as mine mesh.and medical and chemical filters.
